Pololu A-Star 328PB Micro - 3.3V, 12MHz Programmable Module ATmega328PB AVR

Pololu

Pololu A-Star 328PB Micro - 3.3V, 12MHz Programmable Module ATmega328PB AVR

Name: Pololu A-Star 328PB Micro - 3.3V, 12MHz Programmable Module ATmega328PB AVR
Brand: Pololu
SKU: PO3163
Price: 10.65 EUR
Availability: InStock

SKU: PO3163

10,65 €

per pack

incl. 19% VAT plus

Net: 8,95 €

Choose tax zone / country of delivery

Product customisation & sourcing & PCBA one-stop service are available with us.

Request personal offer!

Available immediately

Delivery time: ca. 3 weeks (DE - int. shipments may differ)

The A-Star 328PB Micro is a tiny programmable module featuring the ATmega328PB AVR microcontroller, a backward-compatible replacement for the popular ATmega328P that features more general-purpose I/O and many additional peripherals. This module provides access to all 24 digital input/output pins (of which 9 can be used as PWM outputs and 8 as analog inputs), all on a board measuring only 1.3? × 0.7?. It ships preloaded with an Arduino-compatible serial bootloader that enables programming through the Arduino IDE via a USB-to-serial adapter, and the ISP pins are accessible for programming with an AVR programmer. This version features a 12 MHz resonator and a 3.3 V regulator that can be powered from 3.8 V to 15 V supplies. More product details

Product Information

Product safety information

Manufacturer information:

Pololu Corporation
Pilot Rd. 920
Nevada
Las Vegas, Vereinigte Staaten, 89119
[email protected]
https://www.pololu.com/

Responsible person:

Eckstein GmbH
Am Ostbahnhof 3
Niedersachsen
Clausthal-Zellerfeld, Deutschland, 38678
[email protected]
https://eckstein-shop.de

Dimensions and Weight
GTIN:	4060137044342
HAN:	3163
Category:	Miscellaneous (Teensy/STM32/32U4)
Storage Tiers:	Maintain
Shipping weight:	0,01 kg
Item weight:	0,01 kg
Dimensions ( Length × Width × Height ):	3,00 × 2,00 × 0,30 cm

Product Description

Overview

The A-Star 328PB Micro is a tiny programmable module featuring the ATmega328PB AVR microcontroller, a backward-compatible replacement for the popular ATmega328P that features more general-purpose I/O and many additional peripherals. This module provides access to all 24 digital input/output pins (of which 9 can be used as PWM outputs and 8 as analog inputs), all on a board measuring only 1.3″ × 0.7″. It ships preloaded with an Arduino-compatible serial bootloader that enables programming through the Arduino IDE via a USB-to-serial adapter, and the ISP pins are accessible for programming with an AVR programmer. This version features a 12 MHz resonator and a 3.3 V regulator that can be powered from 3.8 V to 15 V supplies.

Dimensions

Size: 0.7″ × 1.3″ × 0.1″
Weight: 1.5 g

General specifications

Processor: ATmega328PB @ 12 MHz
RAM size: 2048 bytes
Program memory size: 32 Kbytes
Motor channels: 0
User I/O lines: 24
Minimum operating voltage: 3.8 V
Maximum operating voltage: 15 V
Logic voltage: 3.3 V
Reverse voltage protection?: Y
External programmer required?: N
Version: 3.3 V logic, 12 MHz resonator

Identifying markings

PCB dev codes: ac05a
Other PCB markings: 0J11021
Power LED color: yellow

Write the first review for this item and help others make a purchase decision!

User’s Guide

ATmega328PB datasheet

Schematic diagram of the A-Star 328PB Micro

Dimension diagram of the A-Star 328PB Micro
